Technical Specifications

Warranty 2 Years

Converter Type Passive

Adapter Style Cable Adapter

Audio No

Connector Plating Nickel

Cable Jacket Type PVC - Polyvinyl Chloride

Connector A 1 - DisplayPort (20 pin) Male

Connector B 1 - DVI-D (25 pin) Male

Maximum Cable Length 10 ft [3 m]

Maximum Digital Resolutions 1920x1200 / 1080p

Note DP++ (DisplayPort++) port required from video card or video source.

Color Black

Cable Length 10 ft [3 m]

Product Length 120 in [3048 mm]

Product Weight 0.2 lb [0.1 kg]

Shipping (Package) Weight 0.2 lb [0.1 kg]

Included in Package 1 - 10 ft DisplayPort to DVI Video Adapter Converter Cable - M/M

Certifications, Reports and Compatibility
